| Specification | Details |
|---|---|
| Rating | 5 kW |
| Max. DC Input Capacity | 10000 |
| MPPT | 2 |
| IP Rating | IP65 |
| Display Screen | Yes |
| DC Switch | Yes |
| Built-in Battery | No |
| Phase | Single Phase |
| Type | Hybrid LV |
| WiFi | With WiFi |
| Meter | With Meter |
| Use Application | Residential |
| CEC Model | S5-EH1P5K-L (AS4777-2 2020) |
| IEEE 2030.5 CSIP-AUS | Yes, Native |
| Shipping Information | |
| Unit Weight | 18.30 kg |
| Quantity per Pallet | 12 |
| Pallet Weight | 270.60 kg |
| Unit Dimensions | 333 × 249 × 505 mm |
| Pallet Dimensions | 1030 × 1030 × 1060 mm |
| Warranty Information | |
| Product Warranty | 10 Years |
